LPL2SS-RT

Lightplane Linear 2 RT is a competitive streamlined luminaire that features integral drivers along with a PC diffuser. The fixture can up to 110lm/W.
This fixture is recessed mounted. The fixture is available with several LED lamping options including multiple outputs and CCTs, tunable white and colour-changing RGB+White.

DOWNLOAD SPEC SHEET

LPL2SS-RT
LPL2SS-RT
LPL2SS-RT
LPL2SS-RT
Imperial
Imperial Metric

Downloads

Tech Specs

SIZE

75x65mm

BODY

Aluminum

LENS

PC

FINISH

Black, White, Silver, RAL

LED

Standard CCT: 3000K, 3500K, 4000K, CRI90+
Other option: 2700K, 5000K, 5700K, 6500K, RGB, TUNE(2700K-6500K). Contact factory for details.

DRIVER

Built-in

DIMMING

1-10V / 0-10V dimming, dali dimming, traic dimming. Contact factory for other options.

OPTIONAL ADD-ONS

1.5 hour emergency kit, PIR sensor.

Approvals

  • ETL-cut
  • CB
  • CE
  • rohs
  • IP20
  • IK08

Optics & Features
